2023 Chevy Bolt EV | Electric Sedan

EPA-estimated 259 miles (416 km) on a full charge

Type:

Rechargeable energy storage system comprising multiple linked modules

Mass (lb. / kg):

947 / 430

Battery chemistry:

Lithium-ion

Cells:

288

Energy:

65 kWh

Warranty¹:

8 years / 100,000 miles of battery and electric components coverage

Type:

Single motor and gearset

Motor:

Permanent magnetic drive motor

Power:

200 hp / 150 kW

Torque (lb.-ft. / Nm):

266 / 360

Final drive ratio (:1):

7.05:1

120 V:

4 miles / Approx. 6 km of range per hour

240 V:

39 miles per hour of charge - Full charge in approx. 7 hours

DC Fast Charge:

Up to 100 miles in 30 minutes

Independent MacPherson strut-type with direct-acting solid stabilizer bar

Rear Suspension:

Compound crank (torsion beam) with coil springs

Steering Type:

Column-mounted electric power steering

Turning Circle (ft. / m):

34.8 / 10.62

Brake Type:

Four-wheel disc with ABS; electro-hydraulic; partially regenerative

Brake Rotor Size (in. / mm):

Front: 11 / 276 vented
Rear: 10 / 264 solid

Wheel Size:

17-in. aluminum

Tire Size:

Michelin Energy Saver A/S 215/50R17 all-season

102.4 / 2600

Overall Length (in. / mm):

163.2 / 4145

Overall Width (in. / mm):

69.5 / 1765

Overall Height (in. / mm):

63.4 / 1611

Track (in. / mm):

59.1 / 1501 (front)
59.1 / 1501 (rear)

40.1 / 1018 (front - max)
37.9 / 962 (rear)

Legroom (in. / mm):

44.3 / 1124 (front - max)
36.0 / 915 (rear)

Shoulder Room (in. / mm):

54.6 / 1388 (front)
52.8 / 1340 (rear)

Hip Room (in. / mm):

51.3 / 1303 (front)
50.6 / 1286 (rear)

3589 / 1628 – 1LT
3624 / 1644 – 2LT

EPA Passenger Volume        (cu. ft. / L):

93.9 / 2659

Cargo Volume (cu. ft. / L)¹:

16.6 / 470 (behind rear seat)
57.0 / 1614 (rear seat folded)

Standard Tire Pressure Monitor System; tire pressure monitor includes Tire Fill Alert (excludes spare tire)

Chevy Safety Assist package² is standard. Content includes Automatic Emergency Braking, Front Pedestrian Braking, Lane Keep Assist with Lane Departure Warning, Following Distance Indicator, Forward Collision Alert and IntelliBeam auto high beams

Lane Change Alert with Side Blind Zone Alert², Rear Cross Traffic Alert2 and Rear Park Assist2 are standard on 2LT and available on 1LT

HD Rear Vision Camera² is standard on 1LT

HD Surround Vision² (includes HD Rear Vision Camera) is standard on 2LT

Adaptive Cruise Control² is available on 2LT
